Belt filter press industrial grade sludge dewatering equipment operates continuously for 24 hours

Grote Afbeelding : Belt filter press industrial grade sludge dewatering equipment operates continuously for 24 hours

Productdetails:

Plaats van herkomst:	Henan China
Merknaam:	ZTIC
Certificering:	ISO\CE
Modelnummer:	Apparatuur voor cementfabrieken

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	1Set
Prijs:	negotiated
Verpakking Details:	Standaardpakking of volgens de vereiste van de klant

Contact

Gedetailleerde productomschrijving

Riembreedte (mm):	750 tot 3000	Capaciteit (m³/uur) (inlaatconcentratie) (ss1,5-2,5%):	6-9
Droge vaste stof (kg/uur):	110-225	Cake Moisture (%):	63-84.5
Vermogen (pk):	1.5/2.2	Gewicht (kg):	2570-6220
Garantie:	12 maanden	Voorwaarde:	Nieuw
Haven:	Qingdao China
Markeren:	industrial belt filter press , sludge dewatering equipment 24 hours , cement plant belt filter press

Belt Filter Press Industrial Grade Sludge Dewatering Equipment Operates Continuously For 24 Hours

Design Features

The structure has a large stiffness, a steady operation and low noise.
It is equipped with advanced concentration preprocessing equipment to flocculate slurry preferably and decrease running cost.
Gravity dewatering zone is equipped with advanced distributing device to scatter material uniformly and extend filter cloth's service life.
It has a long wedge-shaped dewatering zone and gravity dewatering zone. It can dehydrate material sufficiently and make sure that the material will not overflow.
Dewatering rollers are arranged in a scientific way. Filtrate is respectively discharged from gravity zone, wedge-shaped zone and squeezing zone without disturbing each other. Dewatering rollers has larger diameter and better dewatering effect, they endowed belt f ilter with high treatment capacity, high efficiency and energy saving.
It works continuously from feeding to cake discharging. It has high degree in automation. PLC interface can be installed as needed to realize centralized control by computer.
Power transmission adopts mechanical or frequency stepless speed regulation, so as to get wide speed range and application.
It is equipped with reliable backwash device to ensure good dehydration effect.
It is equipped with pneumatic tensioning and auto deviation adjustment device to ensure safe operation of filter belt.
It adopts infrared safety guarding and comprehensive emergency shutdown device to ensure safety operation.
Different filter belt can be selected based on various filtering material, the filter belt is of high precision.
According to different concentration, it can chose different types of machines: Belt concentration or drum concentration

Product Display

Belt filter press industrial grade sludge dewatering equipment operates continuously for 24 hours 0

Belt filter press industrial grade sludge dewatering equipment operates continuously for 24 hours 1

Product Parameters

Model	Belt Width(mm)	Capacity(m³/hr)(Inlet Concentration)(s.s.1.5-2.5%)	Dry Solid(kg/hr)	Cake Moisture(%)	Power(HP)	Appearance reference size(mm)			Weight(kg)
Model	Belt Width(mm)	Capacity(m³/hr)(Inlet Concentration)(s.s.1.5-2.5%)	Dry Solid(kg/hr)	Cake Moisture(%)	Power(HP)	L	W	H	Weight(kg)
DY750	750	6-9	110-225	63-84.5	1.5	4250	1630	2100	2570
DY1000	1000	8-12	150-300		1.5	4250	1880	2100	2920
DY1500	1500	12-18	225-450		1.5	4250	2380	2100	3590
DY2000	2000	16-24	300-600		2.2	4250	2920	2100	4490
DY2500	2500	20-30	375-750		2.2	4250	3420	2100	5520
DY3000	3000	28-38	420-950		2.2	4250	3920	2100	6220

Q&A

Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.

Q:Delivery time?
A: Parts lead time 1-2months, machines 2-3months.

Q:Payment terms?
A: Accept payment type: T/T, L/C, Western union,Cash.
30% deposit when signed contract. Full payment paid before shipping

Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.

Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
